Product advantages:
Project Name: Horizontal Flow Thermal Power Steam Trap
Type: Low capacity
Series/Model: Model TD42L
Nominal size: 3/4 inch
Connection type: FNPT
Pressure rating: 600 pounds per square inch
Body material: stainless steel
Disc material: stainless steel
Material standard: ASTM A743 grade CA40F
Finish/Color: Electroless nickel plating
Temperature class: 752 degrees Fahrenheit
Length: 85 mm
Product features:
Steam traps should be of the balanced pressure constant temperature type, which can automatically adjust all pressures within their working range
All internal components are made of stainless steel and can be replaced without affecting pipeline connections
Excellent exhaust characteristics during factory start-up and normal operation
Large discharge capacity of its size
Robust internal design provides good life expectancy
450 ° F maximum allowable temperature
• Saturated steam temperature
250 psig at 450 ° F
450 ° F at 0 to 250 psig
• Online horizontal pipeline configuration
6000 lb/h thermal condensation capacity
3/8-inch orifice size
